Maximum Ratings(T=25℃)
|
Parameter |
Symbol |
Value |
Unit |
|
Reverse Voltage |
Vr |
≤20 |
V |
|
Reverse Current |
Ir |
≤10 |
mA |
|
Operating Temperature |
Tstg |
-40~+85 |
℃ |
|
Storage Temperature |
Top |
-55~+125 |
℃ |
|
Forward Voltage |
VF |
0.5~1.3 |
V |
|
Reverse Breakdown Voltage |
VB |
35 |
V |
Spectral characteristics (T=25°C)
|
Parameter |
Symbol |
Value |
Unit |
|
Wavelength Range |
λ |
400-1100 |
nm |
|
Test Sensing Wavelength |
λt |
750 |
nm |
|
Responsivity |
R |
0.40 (Typ.) |
A/W |
|
Active Area Diameter |
Φ |
1.35 |
mm |
|
Dark Current (Vr=10 V) |
Id |
＜10 |
nA |
|
Junction Capacitance (Vr=3 V,F=1MHz) |
Cj |
12 (Typ.) |
pF |
|
Package |
TO-46 |
||
|
Sensor Material |
Si |
||
|
Connector |
FC/PC |
||
Spectral Response
Outline Drawings and Pin Assignment ( mm):
