Features
- Low dark current
- High linearity
- High reliability
- Compliant with RoHS standard
Optical and Electrical Characteristics(Tc=25℃)
|
Parameter |
Symbol |
Test condition |
Min. |
Type |
Max. |
Unit |
|
Optical Wavelength Range |
λ |
800 |
850 940 |
1000 |
nm |
|
|
Spectral Responsivity |
R |
Vr=5V λ=850nm |
0.45 |
0.55 |
— |
A/W |
|
Dark Current |
Id |
Vr=5V 25℃ |
— |
0.5 |
1 |
nA |
|
Capacitance |
C |
Vr=3V，F=1MHz |
— |
4.9 |
— |
pF |
|
Breakdown Reverse Voltage |
Vbr |
Ir=10uA |
35 |
— |
— |
V |
|
ESD |
— |
500 |
V |
|||
Package Dimensions and Pin Description
Unit：mm
